Western blot analysis of IL-1 beta on different lysates with Mouse anti-IL-1 beta antibody (HA601002) at 1/1,000 dilution.
Lane 1: THP-1 whole cell lysate
Lane 2: THP-1 treated with 80nM TPA overnight then treated with 100ng/mL LPS for 6 hours and 300ng/mL BFA for 3 hours whole cell lysate
Lysates/proteins at 20 µg/Lane.
Predicted band size: 31 kDa
Observed band size: 31/28/20 kDa
Exposure time: 5 seconds;
4-20% SDS-PAGE gel.
Proteins were transferred to a PVDF membrane and blocked with 5% NFDM/TBST for 1 hour at room temperature. The primary antibody (HA601002) at 1/1,000 dilution was used in 5% NFDM/TBST at 4℃ overnight. Goat Anti-Mouse IgG - HRP Secondary Antibody (HA1006) at 1/50,000 dilution was used for 1 hour at room temperature.
-
Western blot analysis of IL-1 beta on different lysates with Mouse anti-IL-1 beta antibody (HA601002) at 1/2,000 dilution.
Lane 1: RAW264.7 cell lysate
Lane 2: RAW264.7 treated with 80nM TPA overnight then treated with 100ng/mL LPS for 6 hours add 300ng/mL BFA for 3 hours cell lysate
Lysates/proteins at 30 µg/Lane.
Predicted band size: 31 kDa
Observed band size: 31 kDa
Exposure time: 3 minutes 25 seconds;
4-20% SDS-PAGE gel.
Proteins were transferred to a PVDF membrane and blocked with 5% NFDM/TBST for 1 hour at room temperature. The primary antibody (HA601002) at 1/2,000 dilution was used in 5% NFDM/TBST at 4℃ overnight. Goat Anti-Mouse IgG - HRP Secondary Antibody (HA1006) at 1/50,000 dilution was used for 1 hour at room temperature.
-
Western blot analysis of IL-1 beta on different proteins with Mouse anti-IL-1 beta antibody (HA601002) at 1/2,000 dilution.
Lane 1: Recombinant mouse IL-1 beta
Lane 2: Recombinant rat IL-1 beta
Lane 3: Recombinant human IL-1 beta
Lysates/proteins at 50 ng/Lane.
Exposure time: 30 seconds;
4-20% SDS-PAGE gel.
Proteins were transferred to a PVDF membrane and blocked with 5% NFDM/TBST for 1 hour at room temperature. The primary antibody (HA601002) at 1/2,000 dilution was used in 5% NFDM/TBST at room temperature for 2 hours. Goat Anti-Mouse IgG - HRP Secondary Antibody (HA1006) at 1/50,000 dilution was used for 1 hour at room temperature.
-
Immunocytochemistry analysis of HeLa cells treated with 80nM TPA overnight then treated with 100ng/mL LPS for 6 hours add 300ng/mL BFA for 3 hours labeling IL-1 beta with Mouse anti-IL-1 beta antibody (HA601002) at 1/100 dilution.
Cells were fixed in 100% precooled methanol for 5 minutes at room temperature, then blocked with 1% BSA in 10% negative goat serum for 1 hour at room temperature. Cells were then incubated with Mouse anti-IL-1 beta antibody (HA601002) at 1/100 dilution in 1% BSA in PBST overnight at 4 ℃. Goat Anti-Mouse IgG H&L (iFluor™ 488, HA1125) was used as the secondary antibody at 1/1,000 dilution. PBS instead of the primary antibody was used as the secondary antibody only control. Nuclear DNA was labelled in blue with DAPI.
beta Tubulin (ET1602-4, red) was stained at 1/100 dilution overnight at +4℃. Goat Anti-Rabbit IgG H&L (iFluor™ 594, HA1122) were used as the secondary antibody at 1/1,000 dilution.
-
IL-1 beta Antibody (HA601002) in indirect ELISA.
Indirect ELISA analysis of IL-1 beta was performed by coating wells of a 96-well plate with 50 µl per well of IL-1 beta antigen diluted in carbonate/bicarbonate buffer, at a concentration of 1 µg/mL overnight at 4℃. Wells of the plate were washed, blocked with StartingBlock blocking buffer, and incubated with 50 µl per well of a mouse IL-1 beta monoclonal antibody starting at a concentration of 20 µg/mL and serially diluting it to a concentration of 1.28 ng/mL for 2 hours at room temperature. The plate was washed and incubated with 50 µl per well of an HRP-conjugated goat anti-mouse IgG secondary antibody at a dilution of 1:10,000 for one hour at room temperature. Detection was performed using an Ultra TMB Substrate for 5 minutes at room temperature in the dark. The reaction was stopped with sulfuric acid and absorbances were read on a spectrophotometer at 450 nm.
Please note: All products are "FOR RESEARCH USE ONLY AND ARE NOT INTENDED FOR DIAGNOSTIC OR THERAPEUTIC USE"
